Alltrax XCT Field Map Settings

Alltrax XCT standard controller settings for 48 volt SePex carts:

*Under voltage cut off……38 volts
*Maximum armature amperage……500 (XCT500)
*Maximum regen……60
*Plug braking current……250
*Maximum rpm……6,500
*Turbo on or off……this is already set in the field map
*Street or Turf mode……street/performance, turf/golf
*Select field map

Alltrax XCT standard controller settings for 36 volt SePex carts:

*Under voltage cut off……28 volts
*Maximum armature amperage……300 (XCT300)
*Maximum regen……60
*Plug braking current……250
*Maximum rpm……6,500
*Turbo on or off……this is already set in the field map
*Street or Turf mode……street/performance, turf/golf
*Select field map

Club Car 48 volt IQ Carts:

*Executioner 48 volt
*Rhino 48 volt

EZ-GO 36 and 48 volt DCS and PDS Carts:

*Zombie 36 volt PDS
*El Diablo 36 volt DCS
*Barracuda 48 volt PDS
*Crocodile 48 volt PDS
*T Rex 48 volt DCS
*Yellow Jacket DCS

Yamaha 48 volt G19, G22, G29 carts:

*Gorilla 48 volt
*Street Riot 48 volt

Alltrax Field Map Chart
